M1078A1 LMTV 2.5 Ton Cargo Truck 4x4 All Wheel Drive High Water Rescue Vehicle - SOLD -

Call for similar trucks
NSN #:
2320-01-354-3385

LMTV M1078A1 2 1/2 Ton Cargo Truck

High Water Rescue Vehicle

Emergency Vehicle

HWRV

Features

  • Overall Length x Width x Height (feet):  21' x 8' x 9' 4"
  • Cab has 3 seats, adjustable driver seat and steering wheel, heat & defrost.
  • Approach Angle: 40 degrees
  • Departure Angle: 40 degrees
  • Wheelbase: 153.5" inches
  • Towed Load: 12,000 lbs.
  • Interior cargo bed dimensions: 149" inches x 91" inches
  • Caterpillar 3126 inline 6-cylinder, electronic controlled, fuel-injected, turbocharged and after-cooled
  • Allison MD 3070 PT Automatic/select 7-speed, electronically controlled
  • Full-time all-wheel drive with overall gear ratio of 7.8:1
  • Dual 12 / 24 volt electrical system with re-setable circuit breakers and central power distribution panel
  • 100 amp dual voltage (12 / 24) alternator
  • Dual-circuit, four channel air, anti-lock braking system (ABS) with trailers ABS connectors for emergency towing

Can be used as a High Water Rescue Vehicle / Emergency Vehicle

Fully Processed:

Truck will be thoroughly checked to make sure all lights, signals, wipers and horn are in good operating condition.

- Engine fluids, belts, hoses and filters are checked and replaced as required.

Axle, transmission, transfer case seals and fluids checked and serviced as required.

Service and parking brake systems are checked and serviced including rebuilding or replacing components and axle boots as required.

Tires will have 70% or better tread with like mounted spare tire.

Good glass, mirrors and seat upholstery.

Gauges working.

- New Batteries load tested and properly tied down.

Original paint as shown.

- Provided with Pennsylvania Title.







We check every truck thoroughly to make sure all lights, signals, wipers and horn in operating condition. Good fluids, belts, hoses and filters throughout.  Service and parking brake systems serviced, replaced and adjusted as necessary.  Tires 70% or better and a good mounted spare tire,  Gauges working and confirmed accurate.  Batteries load tested and properly tied down.  All wheel drive and transmission tested, engine tested.

Make
Stewart & Stevenson

Model
M1078

Eastern Surplus Inventory #
23-15

Engine Type
Caterpillar 3126

Curb Weight
18691

Trans Type
Allison MD3070PT 7-Speed

Tire Size
395/85R20

GVW Weight
23692

Call or email with any questions or needs. (215) 332-0500 or dave@easternsurplus.net
